ATB226M035
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet ATB226M035 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$0.07744
Quote It
Technical Details
- Series:ATB
- Package:Bulk
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):8.44Ohm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Bypass, Decoupling
- Ripple Current @ Low Frequency:112 mA @ 120 Hz
- Ripple Current @ High Frequency:160 mA @ 100 kHz
- Impedance:1 Ohms
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.224" (5.70mm)
- Surface Mount Land Size:0.209" L x 0.228" W (5.30mm x 5.80mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
