UPS2ER47MED1TA
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 0.47UF 20% 250V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS2ER47MED1TA Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$0.07787
- 4,000$0.07787
Quote It
Technical Details
- Series:UPS
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:0.47 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:12 mA @ 120 Hz
- Ripple Current @ High Frequency:19.2 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
