EDH476M010A9GAA

Technical Details

• Series:EDH
• Package:Tape & Reel (TR)
• Part Status:Active
• Capacitance:47 µF
• Tolerance:±20%
• Voltage - Rated:10 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:70 mA @ 120 Hz
• Ripple Current @ High Frequency:87.5 mA @ 10 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.248" Dia (6.30mm)
• Height - Seated (Max):0.222" (5.65mm)
• Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
