ATB106M050
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet ATB106M050 Datasheet
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$0.08648
Quote It
Technical Details
- Series:ATB
- Package:Bulk
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):15.92Ohm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Bypass, Decoupling
- Ripple Current @ Low Frequency:98 mA @ 120 Hz
- Ripple Current @ High Frequency:140 mA @ 100 kHz
- Impedance:2.6 Ohms
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.224" (5.70mm)
- Surface Mount Land Size:0.260" L x 0.280" W (6.60mm x 7.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
