USR0G331MDD1TE
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 4V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet USR0G331MDD1TE Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$0.09129
- 3,000$0.09129
Quote It
Technical Details
- Series:USR
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:4 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:165 mA @ 120 Hz
- Ripple Current @ High Frequency:247.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
