UPS2VR47MPD1TA
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 0.47UF 20% 350V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS2VR47MPD1TA Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$0.09356
- 3,000$0.09356
Quote It
Technical Details
- Series:UPS
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:0.47 µF
- Tolerance:±20%
- Voltage - Rated:350 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:11 mA @ 120 Hz
- Ripple Current @ High Frequency:17.6 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
