AVE686M04C12T-F
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 4V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet AVE686M04C12T-F Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$0.1035
- 2,000$0.0988
Quote It
Technical Details
- Series:AVE
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:4 V
- ESR (Equivalent Series Resistance):10.24Ohm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:63 mA @ 120 Hz
- Ripple Current @ High Frequency:78.75 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.217" (5.50mm)
- Surface Mount Land Size:0.209" L x 0.209" W (5.30mm x 5.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
