100ZLH18MEFCT16.3X11
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 18UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 100ZLH18MEFCT16.3X11 Datasheet
-
ECAD Model
- Share
In Stock: 105
Can ship immediately
Pricing:
- 1$0.1064
- 3,000$0.10157
Quote It
Technical Details
- Series:ZLH
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:18 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:112.14 mA @ 120 Hz
- Ripple Current @ High Frequency:267 mA @ 100 kHz
- Impedance:570 mOhms
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
