EEV686M035S9HAA

Technical Details

• Series:EEV
• Package:Tape & Reel (TR)
• Part Status:Active
• Capacitance:68 µF
• Tolerance:±20%
• Voltage - Rated:35 V
• ESR (Equivalent Series Resistance):340mOhm @ 100kHz
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 105°C
• Polarization:Polar
• Ratings:AEC-Q200

• Applications:Automotive
• Ripple Current @ Low Frequency:196 mA @ 120 Hz
• Ripple Current @ High Frequency:280 mA @ 100 kHz
• Impedance:340 mOhms
• Lead Spacing:-
• Size / Dimension:0.248" Dia (6.30mm)
• Height - Seated (Max):0.311" (7.90mm)
• Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
