226KXM100M
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 100V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet 226KXM100M Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$0.10868
- 32,000$0.10375
Quote It
Technical Details
- Series:KXM
- Package:Bulk
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):7.5357Ohm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Bypass, Decoupling
- Ripple Current @ Low Frequency:148 mA @ 120 Hz
- Ripple Current @ High Frequency:370 mA @ 100 kHz
- Impedance:800 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
