B41858C3477M006
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALUM ELECT SINGLE-ENDED 470 UF 1
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 153
Can ship immediately
Pricing:
- 1$0.10918
Quote It
Technical Details
- Series:B41858
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):274mOhm @ 10kHz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:436 mA @ 100 kHz
- Impedance:246 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
