EMVA500ADA3R3MD55G

Technical Details

• Series:Alchip™- MVA
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Capacitance:3.3 µF
• Tolerance:±20%
• Voltage - Rated:50 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:2000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:15 mA @ 120 Hz
• Ripple Current @ High Frequency:22.5 mA @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.157" Dia (4.00mm)
• Height - Seated (Max):0.205" (5.20mm)
• Surface Mount Land Size:0.169" L x 0.169" W (4.30mm x 4.30mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
