RV-16V101MG68U-R
Elna America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet RV-16V101MG68U-R Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$0.12765
- 5,000$0.12185
Quote It
Technical Details
- Series:RV
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:155 mA @ 120 Hz
- Ripple Current @ High Frequency:193.75 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.268" (6.80mm)
- Surface Mount Land Size:0.331" L x 0.331" W (8.40mm x 8.40mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
