ELXY350ETC560MFB5D
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 56UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXY350ETC560MFB5D Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$0.12852
- 2,000$0.08316
Quote It
Technical Details
- Series:LXY
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:56 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:109.2 mA @ 120 Hz
- Ripple Current @ High Frequency:273 mA @ 100 kHz
- Impedance:350 mOhms
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
