157KBM050M

Technical Details

• Series:KBM
• Package:Bulk
• Part Status:Active
• Capacitance:150 µF
• Tolerance:±20%
• Voltage - Rated:50 V
• ESR (Equivalent Series Resistance):120mOhm @ 120Hz
• Lifetime @ Temp.:7000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:304 mA @ 120 Hz
• Ripple Current @ High Frequency:760 mA @ 100 kHz
• Impedance:-
• Lead Spacing:0.197" (5.00mm)
• Size / Dimension:0.394" Dia (10.00mm)
• Height - Seated (Max):0.531" (13.50mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can
