UPS2C220MPD

Technical Details

• Series:UPS
• Package:Bulk
• Part Status:Active
• Capacitance:22 µF
• Tolerance:±20%
• Voltage - Rated:160 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:130 mA @ 120 Hz
• Ripple Current @ High Frequency:208 mA @ 10 kHz
• Impedance:-
• Lead Spacing:0.197" (5.00mm)
• Size / Dimension:0.394" Dia (10.00mm)
• Height - Seated (Max):0.866" (22.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can
