USF1V330MDD1TA
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet USF1V330MDD1TA Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$0.17002
- 2,000$0.16228
Quote It
Technical Details
- Series:USF
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:100 mA @ 120 Hz
- Ripple Current @ High Frequency:200 mA @ 100 kHz
- Impedance:500 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
