566KXM100M
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 56UF 20% 100V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet 566KXM100M Datasheet
-
ECAD Model
- Share
In Stock: 120
Can ship immediately
Pricing:
- 1$0.17388
- 4,000$0.17388
Quote It
Technical Details
- Series:KXM
- Package:Bulk
- Part Status:Active
- Capacitance:56 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):2.9605Ohm @ 120Hz
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Bypass, Decoupling
- Ripple Current @ Low Frequency:182 mA @ 120 Hz
- Ripple Current @ High Frequency:455 mA @ 100 kHz
- Impedance:250 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
