B41858D7127M8
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 120UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41858D7127M8 Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$0.17621
- 12,000$0.16019
Quote It
Technical Details
- Series:B41858
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:120 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):274mOhm @ 10kHz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:436 mA @ 100 kHz
- Impedance:246 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
