50YXH180MEFCTA8X20
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 180UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 50YXH180MEFCTA8X20 Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$0.20117
- 1,000$0.19203
Quote It
Technical Details
- Series:YXH
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:180 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:455 mA @ 120 Hz
- Ripple Current @ High Frequency:910 mA @ 100 kHz
- Impedance:91 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
