EEU-FC0J122LB
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC0J122LB Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$0.20273
- 1,000$0.19351
Quote It
Technical Details
- Series:FC
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:604 mA @ 120 Hz
- Ripple Current @ High Frequency:995 mA @ 100 kHz
- Impedance:65 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):1.024" (26.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
