200CFX22MEFCT810X16
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 200CFX22MEFCT810X16 Datasheet
-
ECAD Model
- Share
In Stock: 2,139
Can ship immediately
Pricing:
- 1$0.21075
- 1,000$0.20116
Quote It
Technical Details
- Series:CFX
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:180 mA @ 120 Hz
- Ripple Current @ High Frequency:360 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.709" (18.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
