UHE1V271MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1V271MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$0.2217
- 1,000$0.20154
Quote It
Technical Details
- Series:UHE
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:735 mA @ 120 Hz
- Ripple Current @ High Frequency:1.05 A @ 100 kHz
- Impedance:69 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
