UHV1A122MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHV1A122MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$0.23929
- 1,000$0.23929
Quote It
Technical Details
- Series:UHV
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:990 mA @ 120 Hz
- Ripple Current @ High Frequency:1.65 A @ 100 kHz
- Impedance:30 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
