UHE1V561MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1V561MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$0.253
- 1,000$0.253
Quote It
Technical Details
- Series:UHE
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.238 A @ 120 Hz
- Ripple Current @ High Frequency:1.65 A @ 100 kHz
- Impedance:42 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
