EKMQ201ELL1R0MF11D
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKMQ201ELL1R0MF11D Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$0.2709
- 2,000$0.2709
Quote It
Technical Details
- Series:KMQ
- Package:Bulk
- Part Status:Active
- Capacitance:1 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:16 mA @ 120 Hz
- Ripple Current @ High Frequency:40 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
