MAL215034681E3
Vishay BC Components/Beyshlag/Draloric- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$0.5152
Quote It
Technical Details
- Series:150 RMI
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:474.5 mA @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:97 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
