EEU-FC1J271B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1J271B Datasheet
-
ECAD Model
- Share
In Stock: 176
Can ship immediately
Pricing:
- 1$0.58826
- 500$0.56152
Quote It
Technical Details
- Series:FC
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:916.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.41 A @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
