UUG2C680MNQ6MS

Technical Details

• Series:UUG
• Package:Tape & Reel (TR)
• Part Status:Active
• Capacitance:68 µF
• Tolerance:±20%
• Voltage - Rated:160 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:2000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:500 mA @ 120 Hz
• Ripple Current @ High Frequency:800 mA @ 10 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.492" Dia (12.50mm)
• Height - Seated (Max):0.886" (22.50mm)
• Surface Mount Land Size:0.535" L x 0.535" W (13.60mm x 13.60mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
