B41896C5128M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41896C5128M000 Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$0.62709
- 3,000$0.57008
Quote It
Technical Details
- Series:B41896
- Package:Bulk
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):179mOhm @ 120Hz
- Lifetime @ Temp.:7000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2.28 A @ 100 kHz
- Impedance:38 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
