B41866C7108M009
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALUM ELECT SINGLE-ENDED 1000 UF
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$0.64162
Quote It
Technical Details
- Series:B41866
- Package:Tape & Box (TB)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):50mOhm @ 10kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:1.895 A @ 100 kHz
- Impedance:46 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
