ELXV101ELL181MK30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 180UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$0.64688
Quote It
Technical Details
- Series:LXV
- Package:Bulk
- Part Status:Active
- Capacitance:180 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:444.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.27 A @ 100 kHz
- Impedance:94 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
