UUG0J332MNQ1ZD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UUG0J332MNQ1ZD Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$0.81373
- 300$0.81373
Quote It
Technical Details
- Series:UUG
- Package:Tray
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.2 A @ 120 Hz
- Ripple Current @ High Frequency:1.38 A @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
