UUE1H101MNS1ZD

Technical Details

• Series:UUE
• Package:Tray
• Part Status:Active
• Capacitance:100 µF
• Tolerance:±20%
• Voltage - Rated:50 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:5000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 125°C
• Polarization:Polar
• Ratings:-

• Applications:Automotive
• Ripple Current @ Low Frequency:335 mA @ 120 Hz
• Ripple Current @ High Frequency:500 mA @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.492" Dia (12.50mm)
• Height - Seated (Max):0.571" (14.50mm)
• Surface Mount Land Size:0.535" L x 0.535" W (13.60mm x 13.60mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
