EDH226M250S9RAA
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 250V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EDH226M250S9RAA Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$0.85588
- 1,200$0.77807
Quote It
Technical Details
- Series:EDH
- Package:Tape & Reel (TR)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:105 mA @ 120 Hz
- Ripple Current @ High Frequency:131.25 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.504" L x 0.504" W (12.80mm x 12.80mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
