EKZH350ELL152ML20S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKZH350ELL152ML20S Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$1.2788
- 10$1.0104
- 100$0.75784
- 500$0.57256
- 1,000$0.50521
- 2,500$0.47152
- 5,000$0.45468
Quote It
Technical Details
- Series:KZH
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.95 A @ 120 Hz
- Ripple Current @ High Frequency:3.25 A @ 100 kHz
- Impedance:15 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
