UUG1A472MNQ1ZD

Technical Details

• Series:UUG
• Package:Tray
• Part Status:Active
• Capacitance:4700 µF
• Tolerance:±20%
• Voltage - Rated:10 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:2000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:1.5 A @ 120 Hz
• Ripple Current @ High Frequency:1.725 A @ 10 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.709" Dia (18.00mm)
• Height - Seated (Max):0.689" (17.50mm)
• Surface Mount Land Size:0.752" L x 0.752" W (19.10mm x 19.10mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
