MAL224656182E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1800UF 25V 4000H
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$1.46712
Quote It
Technical Details
- Series:246 RTI-V
- Package:Box
- Part Status:Active
- Capacitance:1800 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.33 A @ 100 Hz
- Ripple Current @ High Frequency:1.9 A @ 100 kHz
- Impedance:34 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
