180MXG820MEFCSN25X35

Technical Details

• Series:MXG
• Package:Bulk
• Part Status:Active
• Capacitance:820 µF
• Tolerance:±20%
• Voltage - Rated:180 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:3000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:2.14 A @ 120 Hz
• Ripple Current @ High Frequency:3.21 A @ 10 kHz
• Impedance:-
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:0.984" Dia (25.00mm)
• Height - Seated (Max):1.457" (37.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In
