MAL225099817E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 63V 5000H
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 199
Can ship immediately
Pricing:
- 1$1.8496
Quote It
Technical Details
- Series:250 CRZ-V
- Package:Box
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:592.2 mA @ 100 Hz
- Ripple Current @ High Frequency:987 mA @ 100 kHz
- Impedance:120 mOhms
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.654" L x 0.654" W (16.60mm x 16.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
