MAL226099105E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 50V 1500H
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$2.7986
Quote It
Technical Details
- Series:260 CLA-V
- Package:Box
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1500 Hrs @ 150°C
- Operating Temperature:-55°C ~ 150°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive, High Temperature Reflow
- Ripple Current @ Low Frequency:432 mA @ 100 Hz
- Ripple Current @ High Frequency:720 mA @ 100 kHz
- Impedance:70 mOhms
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
