B43509C2827M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALUM ELECT 200V 820UF SNAP-IN
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$2.826
Quote It
Technical Details
- Series:B43509
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):140mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.73 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:230 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
