678D107M063DG5D
Vishay / Sprague
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 678D107M063DG5D Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$3.50346
- 280$3.18497
Quote It
Technical Details
- Series:678D
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):450mOhm @ 20Hz
- Lifetime @ Temp.:-
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:504 mA @ 120 Hz
- Ripple Current @ High Frequency:720 mA @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.906" (23.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
