MAL225722122E3

Technical Details

• Series:257 PRM-SI
• Package:Box
• Part Status:Active
• Capacitance:1200 µF
• Tolerance:±20%
• Voltage - Rated:200 V
• ESR (Equivalent Series Resistance):180mOhm @ 100Hz
• Lifetime @ Temp.:5000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:2.78 A @ 100 Hz
• Ripple Current @ High Frequency:3.892 A @ 10 kHz
• Impedance:140 mOhms
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:1.378" Dia (35.00mm)
• Height - Seated (Max):1.260" (32.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In
