ESMH250VSD393MA50U

Technical Details

• Series:SMH
• Package:Bulk
• Part Status:Active
• Capacitance:39000 µF
• Tolerance:±20%
• Voltage - Rated:25 V
• ESR (Equivalent Series Resistance):13mOhm @ 120Hz
• Lifetime @ Temp.:2000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:-
• Ripple Current @ Low Frequency:7.56 A @ 120 Hz
• Ripple Current @ High Frequency:8.1648 A @ 100 kHz
• Impedance:-
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:1.378" Dia (35.00mm)
• Height - Seated (Max):2.047" (52.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In - 4 Lead
