EKMH500VSN103MA40T
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 50V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKMH500VSN103MA40T Datasheet
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
- 1$4.34
- 10$3.90343
- 100$2.94906
- 500$2.4286
- 1,000$2.25513
- 2,500$2.24687
Quote It
Technical Details
- Series:KMH
- Package:Bulk
- Part Status:Obsolete
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):33mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:4.03 A @ 120 Hz
- Ripple Current @ High Frequency:4.3524 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):1.575" (40.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
