EKMH800VSN822MA63U
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 8200UF 20% 80V SNAP
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
- 1$4.4184
Quote It
Technical Details
- Series:KMH
- Package:Bulk
- Part Status:Active
- Capacitance:8200 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):30mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:-
- Ripple Current @ Low Frequency:4.42 A @ 120 Hz
- Ripple Current @ High Frequency:5.304 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):2.559" (65.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
