ALA8DF241CD500

Technical Details

• Series:ALA8D
• Package:Bulk
• Part Status:Active
• Capacitance:240 µF
• Tolerance:±20%
• Voltage - Rated:500 V
• ESR (Equivalent Series Resistance):859.2mOhm @ 100Hz
• Lifetime @ Temp.:8000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:AEC-Q200

• Applications:Automotive
• Ripple Current @ Low Frequency:2.84 A @ 100 Hz
• Ripple Current @ High Frequency:5.82 A @ 10 kHz
• Impedance:1.628 Ohms
• Lead Spacing:-
• Size / Dimension:1.378" Dia (35.00mm)
• Height - Seated (Max):1.850" (47.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In
