678D477M040EK4D
Vishay / Sprague
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 40V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 678D477M040EK4D Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$4.78583
- 230$4.35078
Quote It
Technical Details
- Series:678D
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:40 V
- ESR (Equivalent Series Resistance):133mOhm @ 20Hz
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:896 mA @ 120 Hz
- Ripple Current @ High Frequency:1.28 A @ 100 kHz
- Impedance:50 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.032" (26.20mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
