ESMH401VNN821MA63U
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$4.80145
Quote It
Technical Details
- Series:SMH
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):303mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:-
- Ripple Current @ Low Frequency:3.61 A @ 120 Hz
- Ripple Current @ High Frequency:5.1623 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):2.559" (65.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
